Lautsprecher-Ausgangskanäle:4 CH
Ausgangsleistung pro Kanal (8 Ohm):1 800 W
Integrierter DSP:Ja
Verstärker Merkmale:DSP integriert
Lautsprecheranschlüsse:speakON NL4
Audio-Netzwerkprotokoll:AES67, Dante
Typ des Verstärkers:Leistungsverstärker
Ausgangsleistung pro Kanal (2 Ohm):2 000 W
Ausgangsleistung pro Kanal (4 Ohm):2 700 W
Total Device Power Output (8 Ohm):7 200 W
Ausgangsleistung Verteilung:Gleiche Leistung pro Kanal, Brückfähige Ausgangskanäle
Physische Audio-Eingangsanschlüsse:XLR (3-Pin)
Analoge Eingangskanäle:4
Digitale Eingangskanäle:8
Physikalische Digital-Audio-Anschlüsse:XLR (3-pin)
Geräuschloser Betrieb:Nein
Rack-Montage:2U rackmount amplifier
Frequency Response:20–20 000 Hz
Schutzfunktionen:Over/under AC-voltage protection, clipping protection, VHF protection, long-term RMS protection, DC protection, thermal protection, short-circuit protection, and power-on/off muting.
Typischer Stromverbrauch:1 940 W
Spannungsversorgungs-Optionen:100 V, 50 / 60 Hz, 120 V, 60 Hz, 230 V / 240 V, 50 Hz
Produktreihe:TTM
Hersteller Code:O1TTM12K4+D
Kompatibel mit:ArmoníaPlus
Gewicht:11.30 kg
