ST5M2/92

From: Renkus-HeinzIDRENK-XSJV

Renkus-Heinz ST5M2/92 is a self-powered three-way mid/high loudspeaker featuring patented CoEntrant technology with CDT-2A driver. Providing 350 Hz to 18 kHz frequency response and 138 dB peak SPL performance, it delivers transparent audio reproduction with 90° horizontal by 20° vertical dispersion. The complex conic horn design ensures consistent beamwidth without conventional rectangular horn issues. Constructed with multi-ply hardwood enclosure weighing 81.6 kg and measuring 81.3 x 61 x 81.9 cm, it includes PM-2MHR PowerNet Tri-Amplifier with RHAON network control, eight-band parametric EQ, and comprehensive monitoring capabilities for signal integrity.

Used Equipment

Vendors

Used Sources

Rental

Vendor Locations

Rental Sources

Product Details

Brand:Renkus-Heinz

Audio Speaker Type:Point Source Loudspeakers, Line Array Modules / Tops

Amplification Type:Active / Self-Powered

Max. SPL:138 dB

Nominal Horizontal Coverage:90 º

Nominal Vertical Coverage:20 º

LF Driver Diameter:10 "

Amount of LF Speakers:0

Physical Digital Audio Connectors:Ethernet (RJ45)

Audio Network Protocol:AES67, CobraNet

Cardioid Capability:No

Audio Speaker Features:Onboard DSP

Amount of Speakers in Device:3

Components:CDT-2A CoEntrant transducer system with 2" HF driver and dual 10" MF transducers, Complex Conic Horn array, PM-2MHR PowerNet Tri-Amplifier module with RHAON networking

RMS Power Handling:675 W

Frequency Response:350–18 000 Hz

Power Options for Active Speakers:120 V, 60 Hz, 230 / 240 V, 50 Hz

Speaker Mounting Options:Ground Stacked, Flyware Compatible, Other Rigging Methods

Housing Colour:White, Other Colours, Black

Cabinet Construction:Multi-ply hardwood with perforated metal grille

Power Options:100 V, 50 / 60 Hz, 120 V, 60 Hz, 230 V / 240 V, 50 Hz

IP Rating:IP20

Manufacturer Code:ST5M2/92

Product Series:ST Series

Optional Accessories:Custom Color, Weather Resistant, TuffTex (black only)

Included Accessories:12-point Universal Mounting Hardware, Handles, AeroQuip fly-track, R-Hang hardware

Compatible with:ST5LR, STX5L

Weight:81.60 kg

Dimensions

Width:61 cm

Length:81.90 cm

Height:81.30 cm

All information is provided without warranty. If you find any errors, please let us know using the feedback button.
