HDMI 1×4 Splitter, 4K60
From: MuxLabIDMUXA-PGMK
HDMI 1×4 Splitter, 4K60
From: MuxLabIDMUXA-PGMK
The MuxLab HDMI 1×4 Splitter, 4K60 (500426) distributes one HDMI 2.0 source to four HDMI displays supporting 4K (3840×2160) at 60Hz with 4:4:4 chroma, HDR, and Deep Color. It is HDCP 1.4 and 2.2 compliant with EDID management via dip switch. Each output provides independent down-scaling from 4K to 1080p. Supports audio formats including LPCM 7.1CH, Dolby TrueHD, Atmos, DTS-HD Master Audio, and DTS:X. With 18 Gbps bandwidth, handles resolutions from 480i to 4K@60FPS. Metal-enclosed unit features rear-panel connectors for clean cabling.
Product Details
Brand:MuxLab
Image Processor Functions:Scaling, HDR / LUT Processing, Format & Signal Conversion
Manufacturer Code:500 426
Included Accessories:Bracket
Power Options:100 V, 50 / 60 Hz, 120 V, 60 Hz, 230 V / 240 V, 50 Hz
Weight:0.55 kg
Dimensions
Width:14 cm
Length:20.50 cm
Height:8 cm
