Mania EFX500

From: MartinIDMART-KHZ9

The Mania EFX500 is a 250 W halogen effect fixture designed to produce sharp, dynamic lighting effects using a rotating parabolic mirror dish and motorized mirror drum with 180° pan and 360° continuous tilt. It features a gobo wheel with 11 colored gobos plus blackout, enabling diverse pattern projection, and includes electronic dimming from 0-100% with strobe capability up to 8 Hz. The fixture supports DMX, standalone (music or auto-trig), and host/client operation, with manual focus adjustable from 2 to 20 meters. Safety-approved with CE, ETL, and CETL certifications, it has forced-air cooling and continuous operation without cooldown. Typical power consumption is 265 W, with switchable 110–120 V and 220–240 V operation.

Used Equipment

Vendors

Used Sources

Rental

Vendor Locations

Rental Sources

Product Details

Brand:Martin

Lighting Fixture Type:Mirror Scanners

Pan & Tilt Movement:Pan/Tilt Mirror Movement, Automated Pan Movement, Automated Tilt Movement

Light Source Wattage:250 W

Lamp Model:Philips ELC 10H 250 W 1000 hour lamp

Light Source Type:Incandescent Lamp

Colour Creation Method:Fixed Colour Filters

Native Light Source Colour Temperature:3 000 K

Fixture Output Colour Temperature Range:3 000 K

Pole Operation:No

IP Rating:IP20

No. of Fixed Colour Wheels:1

No. of Fixed Gobo Wheels:1

No. of Rotating Gobos:11

No. of Rotating Gobo Wheels:1

Beam Iris:No

Dimmer Type:Electronically

Silent Operation:No

Video Mapping:No

Control and Communication Standards:DMX512-A, Standalone, RS-485

Housing Colour:Black

Manufacturer Code:90 430 050

Power Consumption Typical:265 W

Power Options:120 V, 60 Hz, 230 V / 240 V, 50 Hz

Weight:12.50 kg

Dimensions

Width:50 cm

Length:41 cm

Height:23 cm

All information is provided without warranty. If you find any errors, please let us know using the feedback button.

All information is provided without warranty.

If you find any errors, please let us know using the feedback button.

Brand	Martin
Lighting Fixture Type	Mirror Scanners
Pan & Tilt Movement	Pan/Tilt Mirror Movement, Automated Pan Movement, Automated Tilt Movement
Light Source Wattage	250 W
Lamp Model	Philips ELC 10H 250 W 1000 hour lamp
Light Source Type	Incandescent Lamp
Colour Creation Method	Fixed Colour Filters
Native Light Source Colour Temperature	3 000 K
Fixture Output Colour Temperature Range	3 000 K
Pole Operation	No
IP Rating	IP20
No. of Fixed Colour Wheels	1
No. of Fixed Gobo Wheels	1
No. of Rotating Gobos	11
No. of Rotating Gobo Wheels	1
Beam Iris	No
Dimmer Type	Electronically
Silent Operation	No
Video Mapping	No
Control and Communication Standards	DMX512-A, Standalone, RS-485
Housing Colour	Black
Manufacturer Code	90 430 050
Power Consumption Typical	265 W
Power Options	120 V, 60 Hz, 230 V / 240 V, 50 Hz
Weight	12.50 kg
Dimensions
Width	50 cm
Length	41 cm
Height	23 cm
