ELAR Exbar UVBL

From: Elation LightingIDELAT-23YG

The ELAR EXBAR UVBL is a professional 30W outdoor UV LED bar light designed for architectural applications. Featuring 240 high-output 10mm UV LEDs in a 1-meter die-cast aluminum housing with IP44 rating, it provides a fixed 40-degree beam angle with UV-protected Plexiglas front. Equipped with internal power supply and linkable power/data connections, it supports DMX-512 control or standalone operation with 0-100% electronic dimming and strobe functions. Dimensions measure 99.8x7.9x6.9cm (39.25"x3.25"x3") with a weight of 4.5kg. Includes two adjustable mounting brackets for permanent installation in outdoor environments.

Used Equipment

Vendors

Used Sources

Rental

Vendor Locations

Rental Sources

Product Details

Brand:Elation Lighting

Lighting Fixture Type:UV (Ultraviolet, Blacklight), Architectural Lighting

Light Source Wattage:30 W

Light Source Type:Single Colour LEDs

Colour Creation Method:None

Beam Angle Options:Static

Beam Angle Range (w/o accessories):40 º

Horizontal Beam Angle Range:40 º

Vertical Beam Angle Range:40 º

Pole Operation:No

IP Rating:IP44

Beam Iris:No

Dimmer Type:Electronically

Silent Operation:No

Video Mapping:No

Control and Communication Standards:DMX512-A

Application Range:Small (up to 10 m throw)

Housing Colour:Silver

Manufacturer Code:ELAR EXBAR UVBL

Power Consumption Typical:30 W

Power Options:120 V, 60 Hz

Weight:4.50 kg

Dimensions

Width:7.90 cm

Length:99.80 cm

Height:6.90 cm

All information is provided without warranty. If you find any errors, please let us know using the feedback button.

All information is provided without warranty.

If you find any errors, please let us know using the feedback button.

Brand	Elation Lighting
Lighting Fixture Type	UV (Ultraviolet, Blacklight), Architectural Lighting
Light Source Wattage	30 W
Light Source Type	Single Colour LEDs
Colour Creation Method	None
Beam Angle Options	Static
Beam Angle Range (w/o accessories)	40 º
Horizontal Beam Angle Range	40 º
Vertical Beam Angle Range	40 º
Pole Operation	No
IP Rating	IP44
Beam Iris	No
Dimmer Type	Electronically
Silent Operation	No
Video Mapping	No
Control and Communication Standards	DMX512-A
Application Range	Small (up to 10 m throw)
Housing Colour	Silver
Manufacturer Code	ELAR EXBAR UVBL
Power Consumption Typical	30 W
Power Options	120 V, 60 Hz
Weight	4.50 kg
Dimensions
Width	7.90 cm
Length	99.80 cm
Height	6.90 cm
