BVB07

From: BolandIDBAND-AWT2
BVB07
BVB07 image 1
The Boland BVB07 is a 7" high-brightness DayBrite monitor designed for field production, broadcast, and camera applications. Featuring a 2000 nits LCD panel with anti-reflective coating, this device offers 2-way cross conversion (SDI to HDMI and vice versa). It supports high and standard definition video formats including 1080/720/576/480 with HDMI inputs accepting up to 1080p HD. The monitor includes advanced features such as waveform and vector scope (SDI only), marker display, peaking filter, zoom function, false color, audio level metering, and UMD/IMD support. With 1/4-20 mount holes on all four sides and multiple input options including 3G SDI and HDMI, it's suitable for camera, jib, and steadicam setups in demanding production environments.
Used Equipment
0
Vendors
Rental
0
Vendor Locations

Product Details

Brand:Boland
Display Technology:LCD
Display Features:Focus Tools, Monitoring Tools
Screen Diagonal:7.01 in

Native Resolution

Native Resolution Width:1 024 px
Native Resolution Height:600 px
Brightness:2000 nits / 1500 cd/m2
Contrast Ratio:800 : 1
Color Gamut Coverage:Rec. 709
Mounting:Stand, 1/4" female
IP Rating:IP20
Video Wall Compatibility:No
Refresh Rate:16.70 ms

Viewing Angle

Viewing Angle Horizontal:170 º
Viewing Angle Vertical:170 º
Product Series:BVB
Manufacturer Code:BVB07
Included Accessories:Desk stand / Yoke, Detached power supply
Optional Accessories:Safety Glass (removable), Lemo Connector, Hirose to XLR mini, P-Tap to XLR mini, Anton Bauer battery plate, Rackmount
Power Options:100 V, 50 / 60 Hz, 120 V, 60 Hz, 230 V / 240 V, 50 Hz
Weight:0.71 kg

Dimensions

Width:20.60 cm
Height:5.70 cm
Physical Video Input Connectors.:3x BNC, 1x HDMI
Physical Video Output Connectors.:1x BNC, 1x HDMI
